| Product Secification | |||||
| Compatibility | Intel | 115X/17xx/1366/2011 | |||
| AMD | AM5/AM4/AM3/AM2/FM1/FM2/FM3 | ||||
| Single Product Dimension | 157*120*52mm | Retail Gross Weight | 1.14kg | Carton Box Dimension | 685*415*290mm |
| Retail Color Box Dimensions | 219*198*134mm | Carton Gross Weight | 14.92kg | Qty/Carton | 12PCS |
| Fan Specification | |||||
| Fan Dimensions | 120*120*25mm | Fan Blade Quantity | 7PCS | Rated Voltage | DC 12V |
| Material | PBT B.RoHS 2.0 | Cable Length | 400mm | Working Voltage | DC 6-13.2V |
| Bearing Type | Hydraulic bearing | Connector/PWM | FAN 4pin ARGB 3pin | Start Voltage | ≥6V |
| RPM | 800-2000RPM | Lighting mode | ARGB internal 8PCS | Rated Current | Fan：0.25A LED 0.35A |
| Air Flow | 62.82cm | Quantity of fans | 1PCS | Locked Current | / |
| Air Pressure | 1.89 mmH2O | Noise | ≤32dBA | Fan Life | 40000H |
| Radiator Specification | |||||
| Water pump | Radiator | Water pipe | |||
| Dimensions | 70*83*53mm | Dimensions | 157*120*27mm | Tubing Length | 400±10mm |
| Material | PPS | Material | aluminium | Material | rubber |
| RPM | 2300RPM±10% | Water channel | 12PCS | Lighting | / |
| Bearing Type | Sleeve bearing | Noise | ≤26.9dBA | ||
| Lighting | 2510 3-pin dual AURA 5V 3-pin | ||||
