| Applicable models： | VISTA,AUTOBOT-II,Spark(PRO) Series,For all models |
| Reverse Fan Blade for Power Supply Shroud /Bottom plate of Case for Air Intakes | |
| Model Number: | KF300R BK |
| EAN Number: | 6931858791298 |
| Colour: | Black |
| Fans QTY | Fan*3 (FN12A-C8I-R) |
| Unit (Product) Dimensions (mm): | 120mm x 120mm x 25mm (W x H x D) |
| Packaging Dimensions (mm): | 126mm x 82mm x 140mm (W x H x D) |
| Specifications | FN12A-C8I-R |
| Dimensions: | 120 x 120 x 25mm |
| Fan Frame Colour: | Black |
| Fan Blades / Colour: | 9 Reverse Fan Blade/ semi-transparent white |
| LED Qty / Type: | Center 8PCS, Outer ring 16PCS |
| Bearing Type: | Hydraulic Bearing |
| Fan Speed: | 800-1600 rpm ± 10% |
| Max. Air Flow : | 44.35 CFM ± 10% |
| Max. Static Air Pressure: | 1.42mm - H2O |
| Noise Level (max.): | 31.21db(A) |
| Cable Length : | 4pin PWM Power / 3pin Aura, 500/500mm |
| Accessories: | Screws |
| Connectors: | 3pin AURA (M/F) & 4pin PWM Power(M/F) |
| Rated Voltage: | 12V |
| Rated Current (max.): | 0.15A (Max. 0.18A) |
| Rated Input Power: | 1.8W (Max. 2.16W) |
| Test Voltage : | 12V |
| Start Voltage: | 5V |
| M.T.B.F.: | 30,000 hrs |
