Mini PC | 8GB RAM | 256 GB con intel Alder Lake N100
Processor
CPU Intel Alder-N Lake N100 up to 3.4GHz
BIOS AMl EFI BIOS
Chipset SOC
Memory
Type DDR4 SO-DIMM
Max Size Max 16GB
Storage
Emmc optional
SATA III 1*SATAIII 6Gb/s SSD/HDD(7 thickness),Max2TB
M.2 SSD M.2 2280 NVME/ NGFF,Max 2TB
Network
Controller #1 Built-in LAN chip,
Interface 1 x RJ45
wifi / BT
intel 7265/ 3165/ RTL8821CE Dual band WIFI support 2.4GB/5.0GB + BT4.2
Antenna1 FPC WiFi 2.4+BT x1
Antenna1 FPC WiFi 5.0
I/O
USB 2 x USB 3.0, 2 x USB 2.0
Display Interface 2 x HDMI, 1*VGA
LAN 1xRJ45 (100/1000 Gigabit Lan)
Audio 1 x 3.5mm Audio Jack (MIC&Speaker 2 in 1 combo)
DC 1*5.5/2.1mm DC Jack
Power Key 1*Power on/off button
LED Indicators Blue light - Swith on
JAHC Tech
Real-time clock,timing boot Supported
Auto Power On Supported
Wake On Lan Supported
TPM 2.0 CPU interation
Operation System
Windows Win11 Home/Win11 pro/Win11 IOT/ Ubuntu
Linux Supported
Power
Power Type DC-In
Power Adapter 12V/2.5A AC adapter(∮5.5mm power connector)
Mechanical
Dimensions (W x D x H) 12.8*12.8*4.5cm weight:345g
Color box 22.2*15.2*7cm weight:900g
Carton 43.5*34*31.5cm 20pcs/carton, 18.5kg/CTN, 0.046CBM/CTN,
Fan Built in intelligent Fan
Material ABS
Mounting(Optional) Vesa Bracket and screws
Color Iron Grey or ( Balck for OEM )
Environment
Working Enviroment Temp 0~40℃
Stock Enviroment Temp -20~40℃
Relative Humidity 90% @ 40 °C
