| FAN Specifications | FN12A-C8I |
| Dimensions: | 120 x 120 x 25mm |
| Fan Frame Colour: | Black |
| Fan Blades / Colour: | 9 / semi-transparent white |
| LED Qty / Type: | Center 8PCS，Outer ring 16PCS |
| Bearing Type: | Hydraulic Bearing |
| Fan Speed: | 800~1600 rpm ± 10% |
| Max. Air Flow : | 44.35 CFM ± 10% |
| Max. Static Air Pressure: | 1.42mm - H2O |
| Noise Level (max.): | 31.21db(A) |
| Cable Length : | 4pin(M/F) PWM Power / 3pin Aura(M/F), 500/500mm |
| Accessories: | Screws |
| Connectors: | 3pin AURA (M/F) & 4pin PWM Power(M/F) |
| Rated Voltage: | 12V |
| Rated Current (max.): | 0.15A (Max. 0.18A) |
| Rated Input Power: | 1.8W (Max. 2.16W) |
| Test Voltage : | 12V |
| Start Voltage: | 5V |
| M.T.B.F.: | 30,000 hrs |
