| Form Factor (Midi, Micro, Mini ITX, Full) |
Mini Tower |
| Chassis |
SPCC :.08/0.6mm mixed |
| PSU Form Factor |
UP/ATX |
| M/B Form Factor |
M-ATX(200mm), ITX |
| Front Panel |
Metal cover |
| Top Panel |
Metal cover |
| Color |
Front,Top bezel |
/ |
| Side Panel |
Left |
metal cover |
| Right |
metal cover |
| External Drive Bay(s) |
5.25" (ODD) |
*0 |
| 3.5" |
*0 |
| Internal Drive Bay(s) |
3.5" (HDD) |
*2 |
| 2.5" (SSD) |
*3 |
| I/O |
Buttons |
*1 |
| USB1.1 Port(s) |
*0 |
| USB2.0 Port(s) |
*0 |
| USB3.0 Port(s) |
*2 |
| Type-C |
*1(GEN2) |
| Combo Audio |
*1 |
| Card Reader (Support) |
*0 |
| Fan Controller |
*0 |
| RGB Controller |
*0 |
| Controller max. fans |
*0 |
| RGB Controller max. LED strips |
*0 |
| Remote (IR or RF) |
*0
|
| Cooling Fan Support |
Front |
2x 120mm (included) / 2x 140mm (optional) |
| Top |
0 |
| Rear |
1x 120mm (included) |
| Left Side |
*0 |
| Bottom |
3x 120mm / 2x 140mm (optional) |
| WaterCooler Radiator |
Front
|
1x 120mm/240mm/280mm (optional) |
| Top |
*0
|
| Rear |
1x 120mm (optional)
|
| Dust Cover |
Bottom cover with dust filter |
| Slots |
*4 |
| Carton Logo |
GAMEMAX |
| Dimensions |
Chassis |
(L)386*(W)216*(H)367mm |
| Full Case (inc Fascia) |
(L)419*(W)216*(H)388mm |
| Carton |
(L)486*(W)299*(H)503mm |
| Net Weight (Kg) |
kgs |
| Gross Weight (Kg) |
kgs |
| VGA Card Length |
350mm |
| CPU Cooler Height |
169mm |
| SPS Length |
33mm |
