Form Factor (Midi, Micro, Mini ITX, Full) Mini Tower
Chassis SPCC :.08/0.6mm mixed
PSU Form Factor UP/ATX
M/B Form Factor ATX,M-ATX, ITX
Front Panel MESH
Top Panel Metal cover
Color Front,Top bezel /
Side Panel Left Tempered glass
Right metal cover
External Drive Bay(s) 5.25" (ODD) *0
3.5" *0
Internal Drive Bay(s) 3.5" (HDD) *2
2.5" (SSD) *3
I/O Buttons *1
USB1.1 Port(s) *0
USB2.0 Port(s) *0
USB3.0 Port(s) *2
Type-C *1(GEN2)
Combo Audio *1
Card Reader (Support) *0
Fan Controller *0
RGB Controller *0
Controller max. fans *0
RGB Controller max. LED strips *0
Remote (IR or RF) *0
Cooling Fan Support Front 3x 120mm (included) / 2x 140mm (optional)
Top 0
Rear 1x 120mm (included)
Left Side *0
Bottom 3x 120mm / 2x 140mm (optional)
WaterCooler Radiator Front
1x 120mm/240mm/280mm/360mm (included)
Top *0
Rear 1x 120mm (optional)
Dust Cover Bottom cover with dust filter
Slots *7
Carton Logo GAMEMAX
Dimensions Chassis (L)386*(W)216*(H)428mm
Full Case (inc Fascia) (L)419*(W)216*(H)449mm
Carton
(L)523*(W)274*(H)485mm
Net Weight (Kg) kgs
Gross Weight (Kg) kgs
VGA Card Length 350mm
CPU Cooler Height 169mm
SPS Length 33mm
