Technical Specifications
80PLUS? APFC 80+ Plus Compliant
Efficiency Level 80+ Bronze
Noise Level Zero (ECO-ON), 32dba
Form Factor Intel ATX 12 V 2.31
Dimensions 140 mm (W) x 150 mm (L) x 86 mm (H)
Fan Information Fan Size 120 mm
Fan Control ECO-ON/OFF
Fan Bearing Fluid Dynamic Bearing
Life Expectancy 50,000 hours at 40 ??C, 15 % - 65 % RH
Cable Information Modularity Wired Cabling
Cable type Black tube shield along with colors CPU and PCIe connecor
Electrical Features Operating Temperature 0 - 50 ??C (derating from 100 % to 80 % from 40 ??C to 50 ??C)
MTBF @ 25 ??C, excl. fan 100,000 hours
AC Input Full Range AC input (100-240Vac)
Protection OPP, OVP, UVP, OCP, OTP, SCP, SIP
Safety and Environmental Safety and EMC CB, CCC,CE
Environmental Compliance RoHS, WEEE, ErP Lot 6
PSU SPECIFICATION
AC INPUT: AC 100-240V 50-60Hz 12-6.3A
DC Voltage +3.3V +5V +12V -12V +5VSB
Output 20A 20A 60A 0.5A 2.5A
Watt 130W 720W 6W 12.5 W
Max Output 800W
