Form Factor (Midi, Micro, Mini , Full) MICRO
Chassis SPCC :0.4mm
PSU Form Factor Bottom/ATX
M/B Form Factor M-ATX、ITX
Front Panel ABS，MESH
Top Panel metal cover
Branding Box
Unit
(Unit) Position
Side Panel Left Tempered Glass
Right metal cover
External Drive Bay(s) 5.25" (ODD) *0
3.5" *0
Internal Drive Bay(s) 3.5" (HDD) 1*3.5HDD+5*2.5SSD or 2*3.5HDD+3*2.5SSD or 3*3.5HDD+2*2.5SSD or 2*3.5HDD+2*2.5SSD
2.5" (SSD)
I/O Buttons *2
USB1.1 Port(s) *0
USB2.0 Port(s) *1
USB3.0 Port(s) *1
USB3.1 Port(s) *0
HD Audio Support Combo Audio(CTIA)*1
Type C *1(2.)
P-Lock *1
RGB Controller *0
Controller max fans *0
RGB Controller max. LED strips *0
Remote (IR or RF) *0
Cooling Fan Support Front 2x120mm(Fan include),2x140mm(Fan optional)
Top 2x120mm(Fan include) ,2x140mm (Fan optional)
Rear 1x120mm(Fan include)
Left Side 0
PSU Cover 2x120mm (Fan optional)
Water Cooling Support
(Radiator Size) Front 120mm, 140mm,240mm,280mm.360mm
Top 120mm, 140mm,240mm
Rear 120mm*1
Dust Cover Bottom and top cover with dust filter
Slots *5
Carton & Logo GAMEMAX
Dimensions Chassis (L)340*(W)200*(H)436mm
Full Case (inc Fascia) (L)386*(W)205*(H)449mm
Carton (L)486*(W)255*(H)433mm
Net Weight (Kg) 3.3kgs
Gross Weight (Kg) 4.1kgs
VGA Card Length up to 330mm
CPU Cooler Height 155mm
Cable Management Depth 19mm
