Form Factor (Midi, Micro, Mini ITX, Full) Midi
Chassis SPCC :0.45mm
PSU Form Factor Bottom/ATX
M/B Form Factor ATX、M-ATX、ITX
Front Panel ABS,Mesh
Top Panel metal cover
Branding Box
Unit
(Unit) Position
Side Panel Left Tempered Glass
Right metal cover
External Drive Bay(s) 5.25" (ODD) *0
3.5" *0
Internal Drive Bay(s) 3.5" (HDD) *2
2.5" (SSD) *2
1*3.5HDD+3*2.5SSD or 2*3.5HDD+2*2.5SSD
I/O Buttons *2
USB1.1 Port(s) *0
USB2.0 Port(s) *0
USB3.0 Port(s) *2
TYPE-C GEN2 *1
Audio Support Combo Audio*1+MIC*1
Card Reader (Support) *0
P-Lock *0
RGB Controller *1 (ARGB+PWM V5.0 )
Controller max. fans *6
RGB Controller max. LED strips *6
Remote (IR or RF) *1
Cooling Fan Support Front 3x120mm (FN12A-S5)
Top 2x120mm ,2x140mm (Fan optional)
Rear 1x120mm (FN12A-S5)
Left Side 0
PSU Cover 2x120mm (Fan optional)
Water Cooling Support
(Radiator Size) Front 120mm, 140mm,240mm,280mm
Top 120mm, 140mm,240mm
Rear 120mm*1
Dust Cover Bottom and top cover with dust filter
Slots *7
Carton & Logo GAMEMAX
Dimensions Chassis (L)360*(W)210*(H)440mm
Full Case (inc Fascia) (L)436*(W)210*(H)461mm
Carton (L)513*(W)272*(H)476mm
Net Weight (Kg) kgs
Gross Weight (Kg) kgs
VGA Card Length up to 340mm
CPU Cooler Height 170mm
Cable Management Depth 22mm
