80PLUS® Cetificate GOLD
Power Supply Intel ATX 12 V
Dimensions
170 mm (L) x 150 mm (W) x 86 mm (H)
Fan Size 140mm with ARGB LEDs
Fan Control Temperature control
Fluid Dynamic Bearing
Life Expectancy 50,000 hours
Modularity Fully Modular
Cable type Flat black cables
Operating Temperature
MTBF 100,000 Hours (@ 25 °C, Excl. fan)
Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and EMC cTUVus, TUV, CB, CCC, EAC, CE
Environmental Compliance RoHS
RGB Modes Operation Instructions:
Key Function RGB LED Status
Keep the Save memory mode
Press RGB Switch Select RGB light mode
OFF the RGB LED light
Press the Switch again White light flashes once and Entry in o the last mode
Entry Self-Test mode(All led White Light）
Release after Press longer Exit Self-Test mode, Entry Last memory mode
Access external ARGB HUB or 5V 3pin signal from motherboard
