Form Factor (Midi, Micro, Mini ITX, Full) ATX Deskop Chassis
Chassis SPCC 0.8/0.6mm
PSU Form Factor ATX
M/B Form Factor ATX,Micro-ATX, DTX,Mini-ITX
Front Panel Metal Steel
Top Panel ABS, Steel
Side Panel Left Full Mesh Steel
Right Full Mesh Steel
External Drive Bay(s) 5.25" (ODD) *0
3.5" *0
Internal Drive Bay(s) 3.5" (HDD) 3.5" x 1+SSDx 3 or SSD*4
2.5" (SSD)
I/O Buttons *1
USB3.2 Port(s) *2 (TYPE A*1+TYPE C*1)
Audio Combo Audio*1
Card Reader (Support) *0
Cooling Fan Support Front *0
Top 2x120 or 2x140mm (Fan optional)
Rear 1x120mm (Fan optional)
Left Side *0
Bottom 3x120 or 2x140mm (Fan optional)
Water Cooling Support
(Radiator Size) Front *0
Top 240mm*1
Bottom 240mm*1
Dust Cover Bottom and Top with dust filter
Slots *7
Carton Logo GameMax
Dimensions Chassis (L)401*(W)204*(H)386mm
Full Case (inc Fascia) (L)413*(W)204*(H)398mm
Carton (L)470*(W)275*(H)463mm
VGA Card Length 355mm
CPU Cooler Height 168mm
Cable Management Depth Max. 34mm
