Form Factor: M-ATX
Chassis:
SPCC: 1.0mm
PSU Form Factor SFX-L
M/B Form Factor: MATX, ITX
M-ATX Support BTF
Front Panel: Tempered Glass
Top Panel: Tempered Glass
Side Panel:
Left: Tempered Glass
Right: Metal cover, GAMEMAX Proprietary Mesh
External Drive Bay(s):
5.25”(ODD):*0
3.5”:*0
Internal Drive Bay(s):
3.5" (HDD):*1or2
2.5" (SSD):*2or0
I/O:
Buttons: *1
USB 2.0 Port(s):*0
USB 3.0 Port(s):*1
Type C Port(s):*1(GEN2)
Audio Support: *1(Combo Audio)
Card Reader (Support):*0
P-Lock：*0
RGB Controller：*0
Controller Max Fans:*0
RGB Controller max. LED strips：*0
Remote (IR or RF)：*0
Cooling Fan Support:
Front:*0
Top:*0
Rear:3x120mm(Fan optional)
Bottom:1x120mm(Tornado T12-R)
M/B Cover： 1x120mm(Tornado T12-R)
PSU Cover：*0
Water Cooling Support (Radiator Size):
Front:/
Top:/
Rear:120/240/360mm
M/B Cover：*0
Dust Cover: Right side magnetic dust screen
Slots:*5
Carton & Logo: GAMEMAX
Dimensions:
Chassis: (L)340*(W)215*(H)448mm
Full Case (Inc Fascia): (L)340*(W)215*(H)462mm
Carton: (L)530*(W)285*(H)415mm
Net Weight(kg): 5.7
Gross Weight(kg): 7.0
VGA Support: Up to 382mm, Supports vertical mounting
CPU Cooler Height: Up to 160mm
SPS Length: Up to 140mm
Cable Management Depth: 27mm
