Form Factor: ATX
Chassis:
SPCC: 1.0-3.0mm
PSU Form Factor ATX
M/B Form Factor: ATX
Front Panel: N/A
Top Panel: N/A
Side Panel:
Left: Metal
Right: Metal
External Drive Bay(s):
5.25”(ODD): *0
3.5”: *0
Internal Drive Bay(s):
3.5" (HDD): *2
2.5" (SSD): *2
I/O:
Buttons: *1
USB 2.0 Port(s): *0
USB 3.0 Port(s): *2
Type C Port(s): *1 (Gen2)
Audio Support: *1
Card Reader (Support): *0
P-Lock： *0
RGB Controller： *1 （GMX V4.0 ARGB/PWM HUB）
Controller Max Fans: *9
RGB Controller max. LED strips： *9
Remote (IR or RF)： *1
Cooling Fan Support:
Front: *0
Top: *0
Rear: *0
Bottom: *0
M/B Cover： *0
PSU Cover： *0
Water Cooling Support (Radiator Size):
Front: *0
Top: *0
Rear: *0
M/B Cover： *360MM (M/B back)
Dust Cover: /
Slots: *3 （Vertical - mounted graphics card）
Carton & Logo: GAMEMAX
Dimensions:
Chassis: (L)498*(W)254*(H)463mm
Full Case (Inc Fascia): (L)498*(W)254*(H)470mm
Carton: (L)610*(W)365*(H)575mm
Net Weight(kg): 12.5
Gross Weight(kg): 14.2
VGA Support: 400mm
CPU Cooler Height: 105mm
SPS Length: 230MM
